5-Phase Stepper Motors PKP/PK Series
฿6,000.00piece
- High torque, low vibration
- Frame Size: 20 to 85 mm
- Geared type and type including an encoder also available
| Phase |
5 |
|---|---|
| Motor Frame Size[mm] |
20 |
| Maximum Holding Torque[N·m] |
0.0231 |
| Rated Current[A/Phase] |
0.75 |
| Basic Step Angle[°] |
0.72 |
| Type |
Standard |
| Shaft |
Single |
15
Items sold in last 3 days
มีสินค้าอยู่ 30
140
People watching this product now!
คำอธิบาย
High Accuracy
Since the step angle of 5-phase PKP Series is at 0.72˚ (high-resolution type at 0.36˚) and the stopping accuracy is at ±0.05˚, highly accurate positioning is possible. In addition, the stop position accuracy controlled by a microstep driver has almost the same high accuracy as that controlled by a full-step driver.
Low Vibration
As the 5-phase PKP Series has a small basic step angle of 0.72˚ (0.36˚ for high-resolution type), it is lower in vibration and noise than 2-phase stepper motors with a basic step angle of 1.8˚. Also, vibrations and noise can be further reduced through control with the driver of the microstep drive.
Compact Encoder Equipped
When frame size is 56.4 mm
- *The orange area in the dimensions diagram is the encoder section.
